主要特性和功能
出色的硬件性能可以尽可能地提升您的设计性能，包括优异的相位噪声和杂散特征
利用优异的 ACPR 和输出功率，驱动功率放大器并表征非线性特性
经工厂均衡的 160 MHz 射频带宽，可以更好地测试宽带器件
利用 Signal Studio 软件，可以缩短生成 LTE、WLAN 和 GNSS 等信号所需的时间
3 年校准周期和全面的自我维护解决方案确保降低您的拥有成本

性能水平 ◆◆◆◆◇◇
1 GHz 时的输出功率 -144 dBm 至 +26 dBm
1 GHz 时，20 kHz 频偏处的相位噪声 -146 dBc/Hz
频率转换 ≤ 800 μs
1 GHz 时的谐波 <-35 dBc
IQ 内部/外部调制带宽 160 MHz 至 200 MHz
1 GHz 时的非谐波 -96 dBc
扫描模式
列表
步进
基带发生器模式 波形回放和实时
软件——通用
模拟 I/Q 输入
I/Q 波形
多音，NPR
噪声（AWGN）
相位噪声减损
脉冲
脉冲串发生器
AM, FM, PM
ASK
FSK, MSK
MATLAB
PSK
QAM
软件——蜂窝/无线连通性
蓝牙
1xEV-DO
802.11 WLAN
802.16 WiMAX
EDGE Evolution
GPRS/EGPRS
GSM/EDGE
HSPA, HSPA+
LTE
NADC, PDC
PHS, DECT
TD-SCDMA
TETRA, APCO
W-CDMA
cdma2000
cdmaOne
软件——音频/视频广播
调幅立体声，RDS/RBDS
ATSC, ATSC-M/H
CMMB
DAB, DAB+, DMB-Audio
DOCSIS DS
DTMB
DVB-C/S/S2
DVB-T/H/T2
ISDB-T/TSB/TB/Tmm
J.83 Annex A/B/C
T-DMB
软件——检测/定位/跟踪/导航
伽利略
GNSS 波形
GLONASS
GPS
波形回放存储器 1024 Msa
1 GHz 时的频率调制最大偏移 4 MHz
100 kHz 频偏时的频率调制率 直流至 7 MHz
普通模式下的相位调制最大偏移 0.5 rad 至 8 rad
高带宽模式下的相位调制最大偏移 0.05 rad 至 0.8 rad
幅度调制最大深度 100%
幅度调制率
0 至 50 kHz

可用应用 是
矢量 是
选件和升级
选件
Frequency Range
Connector Configuration
General Performance Features
Vector System Features
Analog Modulation
Vector Firmware Applications
Additional Features
Calibration Documentation
Waveform 5-pack Licenses
Waveform 50-pack Licenses
Accessories
Documentation
Signal Creation Software
保修、校准和服务
售后升级
选件
了解详细信息: 查看配置指南

Frequency Range
N5182B-503 9 kHz 至 3 GHz 频率范围
N5182B-506 9 kHz 至 6 GHz 频率范围
Connector Configuration
N5182B-1EM 将所有连接器移至后面板
General Performance Features
N5182B-UNZ 快速切换
N5182B-UNX 低相位噪声
N5182B-UNY 增强的超低相位噪声性能
N5182B-1EA 大输出功率
N5182B-1EQ 小功率，< -110 dBm
N5182B-1ER 灵活的参考输入（1 - 50 MHz）
N5182B-302 Avionics License
N5182B-099 期限延长的许可证密匙升级能力
Vector System Features
N5182B-UNV 增强的动态范围
N5182B-660 升级基带信号发生器，增加实时能力
N5182B-657 基带信号发生器的射频带宽从 80 MHz 升级至 160 MHz
N5182B-656 ARB 基带信号发生器（80 MHz 射频带宽，32 Msa）
N5182B-1EL 差分 I/Q 输出
N5182B-023 Upgrade baseband generator memory from 32 Msa to 1 Gsa
N5182B-022 Upgrade baseband generator memory from 32 Msa to 512 Msa
N5182B-UN7 内置比特误码率分析仪，固定永久许可证
Analog Modulation
N5182B-303 多功能函数发生器
N5182B-320 脉冲序列发生器、固定永久许可证
N5182B-UNT 调幅、调频、相位调制
N5182B-UNW 窄脉冲调制
Vector Firmware Applications
N5182B-004 数字输入端口可与 N5102A 连接
N5182B-003 数字输出端口可与 N5102A 连接
N5182B-432 相位噪声减损
N5182B-431 定制设计调制
N5182B-430 多音频和双音频
N5182B-403 经过校准的 AWGN
Additional Features
N5182B-006 仪器安全特性和可拆卸存储卡
N5182B-009 Internal solid state memory
N5182B-012 用于相位相干的 LO 输入/输出
Calibration Documentation
N5182B-UK6 Commercial calibration certificate with test data
N5182B-A6J ANSI Z540-1-1994 校准
N5182B-AMG 校准 + 不确定度 + 保护频段（认证）
Waveform 5-pack Licenses
N5182B-229 Waveform license 5-pack9
N5182B-228 Waveform license 5-pack8
N5182B-227 Waveform license 5-pack7
N5182B-226 Waveform license 5-pack6
N5182B-225 Waveform license 5-pack5
N5182B-224 Waveform license 5-pack4
N5182B-223 Waveform license 5-pack3
N5182B-222 Waveform license 5-pack2
N5182B-221 5 种波形一组的波形许可证
Waveform 50-pack Licenses
N5182B-259 Waveform license 50-pack10
N5182B-258 Waveform license 50-pack9
N5182B-257 Waveform license 50-pack8
N5182B-256 Waveform license 50-pack7
N5182B-255 Waveform license 50-pack6
N5182B-254 Waveform license 50-pack5
N5182B-253 Waveform license 50-pack4
N5182B-252 Waveform license 50-pack3
N5182B-251 Waveform license 50-pack2
N5182B-250 50 种波形一组的波形许可证
Accessories
N5182B-AXT Hard transit case
1CN106A Handle kit 88.1mm H (2U) - two front handles,  Palette 2015
1CP104A Rack mount flange and handle kit 88.1mm H (2U) - brackets, handles, hole plugs, Palette 2015
1CR112A Rack Slide Kit, Mounting lengths 279.4-406.4mm, Palette 2015
1CM110A Rack mount flange kit 88.1mm H (2U) - two flange brackets, four hole plugs, Palette 2015
1CM010A Rackmount Flange Kit 88.1mm H (2U) - Two Flange Brackets, Four Hole Plugs
1CN006A 把手套件 88.1 毫米（高）（2U）－－两个前把手
1CP004A Rackmount Flange and Handle Kit 88.1mm H (2U) - Brackets, Handles, Hole Plugs
1CR012A Rack Slide Kit, Mounting lengths 279.4-406.4mm
N5182B-CVR Front panel cover
Documentation
N5182B-ABJ Japan - Japanese printed users guide
Signal Creation Software
N6171A MATLAB 软件
N7600B Signal Studio for W-CDMA/HSPA+
N7601B Signal Studio for cdma2000/1xEV-DO
N7602B Signal Studio for GSM/EDGE/Evo
N7605B Signal Studio for Real-Time Fading
N7606B Signal Studio for Bluetooth
N7607B Signal Studio for DFS Radar Profiles
N7608B Signal Studio 定制调制软件
N7609B Signal Studio for Global Navigation Satellite Systems (GNSS)
N7610B Signal Studio for Short Range Communications
N7611B Signal Studio for Broadcast Radio
N7612B Signal Studio for TD-SCDMA/HSPA
N7614B Signal Studio 功率放大器测试软件
N7615B Signal Studio for Mobile WiMAX
N7617B 适用于 WLAN 802.11a/b/g/j/p/n/ac/ah 的 Signal Studio 软件
N7620B Signal Studio for Pulse Building
N7621B Signal Studio for Multitone Distortion
N7623B Signal Studio for Digital Video
N7624B Signal Studio for LTE / LTE-Advanced / LTE-Advanced Pro FDD 信号生成软件
N7625B Signal Studio for LTE / LTE-Advanced TDD 信号生成软件
E8900-D10 USB read-only licensing dongle - FLEX10
